Artistic License Net-Lynx

Artistic License Net-Lynx

Net-Lynx O/P is a desktop ethernet to DMX512 converter. Converting Art-Net ethernet data into two universes of DMX512/RDM, or sACN into two universes of DMX512.

SKU: ALNETLX Category:

Net-Lynx O/P is a desktop ethernet to DMX512 converter. Converting Art-Net ethernet data into two universes of DMX512/RDM, or sACN into two universes of DMX512.

Net-Lynx O/P is housed in a small, robust extruded case. The ethernet connection is made via a latching Neutrik EtherCON connector. The power input can be either from the ethernet cable using the IEEE 802.3 standard, or from an external power supply.

The front panel provides two DMX512-A outlets that are RDM compatible. Configuration is simplicity itself. The three rotary dials are used to select the required DMX512 universe. Alternatively, the product can be remotely configured.

  • DMX routing by Ethernet
  • Compatible with Art-Net and sACN
  • Two DMX512 outputs
  • 10BaseT Ethernet Port
  • Compatible with DMX512-A
  • RDM V1.0
  • DHCP supported
  • Power indicator
  • Data activity indicators
Artistic License Net-Lynx
Weight 1 kg
Manufacturer

Artistic Licence
